CALIBER® D62R14H308MH4 4U Rack mount Workstation
CALIBER® D62R14H308MH4 4U Rack mount Workstation
System Specifications
The following table lists the system specifications for CALIBER® D62R14H308MH4 Workstation
| Components | Specification |
| Chipset | 1 x Intel C621A Chipset Motherboard having 4 PCI-E 4.0 x16 slots |
| Processor Installed | 2 x 3rd Generation Intel Xeon Gold 6330 Processor [28 Cores | 56 Threads | 2.00 GHz Processor Base Frequency | 3.10 GHz Max Turbo Frequency | 42 MB Cache | 205 W TDP] |
| Processor Thermal Kit | 2 x Socket P-4, LGA4189 actively air-cooled thermal kit |
| Memory Installed | 8 x 32 GB DDR4 ECC Registered Memory @ 3200 MHz expandable to 512 GB |
| Storage Drive Installed | 3 x 4TB 3.5” 7200 RPM SAS 12Gb/s Hard Disk Drive |
| RAID Support | 1 x 12 Gb/s RAID controller supporting RAID levels 0, 1, 5, 1+0, 50, 60 |
| Network controller | 1 x Dual LAN 10GBase-T Ethernet Controller |
| Expansion Slots | 4 x PCI-E 4.0 x16 |
| Ports | 6 x USB (2.0 and 3.0) ; 2 x 10 GBE ; 1 x VGA |
| Enclosure Form Factor and Power supply Unit | 1 x 4U Rack mount chassis supporting 8 x 3.5” hot-swap pluggable SAS hard disk bays with 1600W 80 plus Platinum rated 1+1 redundant power supply and telescopic sliding rails |
| Cables & Power cord | 1 x India style 3-pin (Plug-D) IA6A3 6A 250V 1.8M power cord with IEC60320-C13 connector |
| Operating System | 1 x Rocky Linux 9 operating system pre-installed |
| Monitor | 1 x 24” IPS FHD LED backlight Monitor |
| Keyboard and Mouse | 1 x Wired USB QWERTY layout standard keyboard and USB wired 2-button optical scroller mouse |
| Warranty | Five years onsite warranty on the supplied hardware against manufacturing defects |
