Resilienté® DZEN3R12H312MK4 2U Rackmountable Server
Resilienté® DZEN3R12H312MK4 2U Rackmountable Server
System Specifications
The following table lists the system specifications for Resilienté® DZEN3R12H312MK4 Server
| Components | Specification |
| Chipset | 1 x Dual socket server board featuring AMD SoC |
| Processor Installed | 2 x 3rd generation AMD EPYC 7763 processor [Specifications per processor: 64 cores | 128 threads | 2.45 GHz base .. 3.50 GHz max Boost clock | 256 MB L3 cache | 280 W TDP | socket SP3, LGA4094 layout | 2S scalability | upto 128 lanes of PCIe Gen4.0 | 8 x memory channels | 3200 MHz max. memory speed | 7 nm AMD “Zen 3 – Milan” micro-architecture] |
| Processor Thermal Kit | 2 x Socket SP3, LGA4094 layout 2U actively air-cooled thermal kit |
| Memory Installed | 8 x 64GB [512 GB] DDR4 ECC registered 3200 MHz memory expandable to 2048 GB |
| Storage Drive Installed | 2 x 2 TB NVMe M.2 solid state drives built into Mirror RAID through OS 4 x 12 TB 7.2K RPM SAS 12 Gb/s Hard Disk Drive |
| Raid Controller | 1 x SAS 12 Gb/s RAID controller featuring 8 GB cache supporting RAID levels 0, 1, 5, 1+0, 50, 60 |
| Graphics Controller | 1 x Nvidia RTX A6000 48 GB GDDR6 GPU Memory Graphics Card |
| Ethernet Controller | 1 x Ethernet controller dual-port 10G Base-T RJ-45 1 x Ethernet controller (add-in) PCIe dual-port 10GBase-T (10 GbE) SFP+ |
| Server management | 1 x Server remote management with dedicated management port |
| Transceivers and cables | 4 x Transceiver SFP+ supporting 10Gb/s transfer rates 2 x 2 Metres LC- LC cable |
| Enclosure Form Factor and Power supply Unit | 1 x 2U rackmount enclosure with 12 x 3.5″/2.5″ dual-profile SAS hot-swap drive bays with 2000W 1+1 redundant 80+ Platinum rated power supply unit and sliding railkit |
| Keyboard and Mouse | 1 x Wired USB QWERTY layout standard keyboard and USB wired 2-button optical scroller mouse |
| Monitor | 1 x 24” LED Monitor with IPS technology |
| Operating System | 1 x Rocky Linux latest stable version operating system pre-installed |
| Peripheral Ports | 4 x USB 3.0 ; 1 x VGA ; 2 x 10G Base-T; 1 x dedicated management port |
| Cables & Power cord | 2 x 3-pin India style (Plug-D) IA6A3 6A 250V 1.8M power cord with IEC60320-C13 connector |
| Warranty | 5 years onsite warranty on supplied hardware against manufacturing defects |
